LMS Data

LJ6C Floor Box Cat6 UTP RJ45 Data Module (LP-LJ6C6)

LJ6C Floor Box Cat6 UTP RJ45 Data Module (LP-LJ6C6)

Regular price $3.00 USD
Regular price Sale price $3.00 USD
Sale Sold out
Tax included.

The LMS Data LP-LJ6C6 is a certified CAT6 UTP data outlet module commonly used within under floor boxes found in offices, public institutions and areas of high density data points. Easy to terminate via its colour-coded rear IDC, the module comes complete with a dust-prevention door together with a flip-out ID market window.

Fully Gigabit Ethernet certified means its ideal for running legacy and advanced networking protocols up to Gigabit Ethernet (1000BaseT).
Long-life, nickel plated female RJ45 means it has a long insertion life and is covered by our Synthesis 25-year warranty.


Key Features




Certified CAT6 Performance for Gigabit Ethernet


Popular Krone(tm) KATT Dual Purpose IDC Punchdown

Spring-Loaded Dust Prevention Door and Lip-Out Window ID Tab

Part of the Synthesis 25-Year Warranty Solution





Applications

Office, Education and Home Structured Cabling Installs

Ideal for Gigabit Ethernet (1000Mbps) Data Networks

Ideal for Under Floor Data and Distribution Boxes





Product Code



Part Number: LP-LJ6C6

EAN: 8400800031921

Weight: 0.02 Kg approx




Technical Specifications


Dimensions                           2.5cm(W) x 3.8cm(H) x 2cm(D)

Conformance                        TIA-EIA-568A/568-B Coded IDC

Performance                         10/100/1000Mbps Gigabit Compliance

RJ45/IDC Connects               Nickel and Phosphor Bronze

Port Identification                  Flip-Out Window ID Tab


* Specifications and product design are subject to change. E&OE.


What's a Data Module? Part of Structured LAN cable installation, data modules are normally located nearby to connected PCs, LAN Printers, IP Cameras - basically all LAN end points. Used with faceplates and back boxes (to attach them to a wall surface) data modules provide a neat and tidy way to connect to your LAN infrastructure.

View full details
Cat6 UTP data module
Cat6 UTP data module
RJ45 floor box module
Floor box data outlet
Network connectivity module
Floor box RJ45 data
Floor box networking

LJ6C Floor Box Cat6 UTP RJ45 Data Module (LP-LJ6C6)

$3.00

(exVAT)


The LMS Data LP-LJ6C6 is a certified CAT6 UTP data outlet module commonly used within under floor boxes found in offices, public institutions and areas of high density data points. Easy to terminate via its colour-coded rear IDC, the module comes complete with a dust-prevention door together with a flip-out ID market window.

Fully Gigabit Ethernet certified means its ideal for running legacy and advanced networking protocols up to Gigabit Ethernet (1000BaseT).
Long-life, nickel plated female RJ45 means it has a long insertion life and is covered by our Synthesis 25-year warranty.


Key Features




Certified CAT6 Performance for Gigabit Ethernet


Popular Krone(tm) KATT Dual Purpose IDC Punchdown

Spring-Loaded Dust Prevention Door and Lip-Out Window ID Tab

Part of the Synthesis 25-Year Warranty Solution





Applications

Office, Education and Home Structured Cabling Installs

Ideal for Gigabit Ethernet (1000Mbps) Data Networks

Ideal for Under Floor Data and Distribution Boxes





Product Code



Part Number: LP-LJ6C6

EAN: 8400800031921

Weight: 0.02 Kg approx




Technical Specifications


Dimensions                           2.5cm(W) x 3.8cm(H) x 2cm(D)

Conformance                        TIA-EIA-568A/568-B Coded IDC

Performance                         10/100/1000Mbps Gigabit Compliance

RJ45/IDC Connects               Nickel and Phosphor Bronze

Port Identification                  Flip-Out Window ID Tab


* Specifications and product design are subject to change. E&OE.


What's a Data Module? Part of Structured LAN cable installation, data modules are normally located nearby to connected PCs, LAN Printers, IP Cameras - basically all LAN end points. Used with faceplates and back boxes (to attach them to a wall surface) data modules provide a neat and tidy way to connect to your LAN infrastructure.
